SLE SLE4000 - O 2 & Flow System Calibration

(Model K) Page 25
5.2.2 Jet Calibration
The jet calibration panel allows the forward jet, reverse jet and mean jet to be
adjusted. Also contained within this panel are the controls to adjust the inspiratory
and expiratory leading edges of the CMV wave form.
5.3 O
2
& Flow System Calibration
The O
2
& Flow System calibration panel allows the calibration of the oxygen
monitoring system (2 point calibration, 100% and 21%) and the calibration of the
flow system.
The flow system is a
factory set system
and requires an ETU-
2 for calibration.
Note: O
2
calibration
time is 7 minutes.
