Page 228 (Model K)
- Item Not illustrated
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
2 -1 L0274/M3 Base plate & side door assembly
(See figure 1 for next highest assembly)
RF
5 T1269/M3 .Side Door 1
Attaching Parts
10 T1252/M6 ..Stud plate 2
15 T1239/01 ..Plate, hinge 2
20 H3091 ..Nut, (M3) 4
25 H3094 ..Washer, shakeproof (M3) 4
30 H4095 ..Washer, plain Nylon (M4) 2
35 M0607/09 ..Foot, rubber 4
40 T1194 .Pneumatic Unit Base Tray 1
To Next Page
