SLE SLE4000 - Page 230

Page 230 (Model K)
- Item Not illustrated
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
3 -1 L4007-1002 Front facia assembly
(See figure 1 for next highest assembly)
ARF
5 N6633 .Seal, cover 1
10 N6632 .Seal, screen 1

15 W0334/01 .Loom, flow senor 1
20 M0767/06 .Core, ferrite hinged 1
25 M0767 .Core, ferrite hinged 1
Attaching Parts
30 T1261 ..Bezel 1

35 T1297/0F/01 .Label, main A 1
40 T1297/0F/03 .Label, LED 1
45 T1297/0F/02 .Label, top A 1

50 L4007-1004 .LED, loom assembly
(See items 55-60)
1

-55 D0715 ..LED, green 1
-60 W0333 ..Loom 1

65 T1268/M2 .Front facia 1
-70 M0434 ..Cable tie 1
-75 M0433/01 ..Base, cable tie 1

