SLE SLE4000 - Page 247

(Model K) Page 247
4 385 M0856 .Clamp, cable tie 1
390 M0305/10 .Spacer, Nylon (12mm long) 1
Attaching Parts
395 H3220 ..Screw (M3 x 20mm) 1
400 H3093 ..Washer (M3) 2

405 T1240 .Screen Mounting Plate 1

410 N6631/13 .Inverter PCB 1
Attaching Parts
415 M0305/36 ..Pillar 3
420 H3206 ..Screw (M3 x 6mm) 2
425 H3091 ..Nut (M3) 3
430 H3094/01 ..Washer crinkle (M3) 3

435 M0915 .Power Supply Unit 1
Attaching Parts
440 H3208 ..Screw (M3 x 8mm) 4

445 W0328 .Main Loom
(For Serial Nº: 42000 onwards)
1

460 W0327 .Cable, ribbon assy 1
Attaching Parts
465 M0306 (1) ..Screwlock, screw 4
470 M0306 (2) ..Screwlock, nut 4
475 M0306 (3) ..Screwlock, washer 4

480 N0280/75 .Tube, Polyurethane (Length165mm) 1
-485 M0434 .Cable tie 1

490 M0306 (1) ..Screw 2
495 M0306 (2) ..Nut 2
500 M0306 (3) ..Washer 2

Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
