SLE SLE4000 - Page 259

(Model K) Page 259
Fig
Item SLE Part Nº Description Effectivity
code
Units
Per
Assy.
5 1 L0288/KV Pneumatic module assembly
(See Figure 1 for next highest assembly)
RF
5 N0280/75 .Tube, Polyurethane (Length 200mm) 1
10 N0280/75 .Tube, Polyurethane (Length 320mm) 1
15 N0280/75 .Tube, Polyurethane (Length 140mm) 1
20 N0280/75 .Tube, Polyurethane (Length 255mm) 1
25 N0280/75 .Tube, Polyurethane (Length 210mm) 1
30 N0280/75 .Tube, Polyurethane (Length 140mm) 1
35 N0280/75 .Tube, Polyurethane (Length 230mm) 1
40 N0280/75 .Tube, Polyurethane (Length 210mm) 1
45 N0280/75 .Tube, Polyurethane (Length 200mm) 1
50 N0280/75 .Tube, Polyurethane (Length 90mm) 1
55 N0288/01 .Flow controller 1
60 N0280/40/01 .Tube connector, equal tee 1
65 N0280/75 .Tube, Polyurethane (Length 110mm) 1

70 N0280/75 .Tube, Polyurethane (Length 110mm) 1
75 N6642 .Tube connector, plugin reducer 1
80 N0280/40/01 .Tube connector, equal tee 1
85 M0434 .Cable tie 1
90 N0280/75/01 .Tube, Polyurethane (Length 650mm) 1
95 N6642 .Tube connector, plugin reducer 1
100 N0280/75 .Tube, Polyurethane (Length 195mm) 1
105 N0280/75 .Tube, Polyurethane (Length 115mm) 1

110 N0280/11/01 .Cover plate, Oxygen cell 1
115 T1270/05 .Label, Oxygen cell cover plate
Label part of T1270 set
1
120 N0280/11/02 .Screw, captive (M3 x 10mm) 2
125 N2191/10 .Oxygen sensor cell 1

1
130 N0288/02 .Manifold assembly, pressure regulators
(See items 150-175)
1
Attaching parts
135 H4091/03 ..Nut, self locking (M4) 4
140 H4093 ..Washer, plain (M4) 4

