(Model K) Page 47
4.Remove the four nuts and washers (H)
securing the pressure regulator manifold
assembly.
5. To remove the pressure
regulators (I & J) from the
manifold block (K) remove
the screws (L), two per
regulator.
Note: that the ‘O’ rings (M) will be released once the regulator has been
removed.
6. To remove the SV13 solenoid base (N) from the mainfold block (K) remove the two screws
(O).
7. Assembly is reversal of removal.
Setup: Full system calibration is required for this component.
