(Model K) Page 83
Warning: If the ventilator is under a
warranty agreement removal of the
inner covers may void the agreement.
Please refer to the warranty
documentation.
3. Remove the screws (B) (2 screws)
(C) (4 screws) to release the electronic
inner cover.
4. Remove the screws (D) (6 screws) to
release the pneumatic unit base plate.
5. Rest the ventilator on a soft pad.
Warning: Disconnect the ventilator
from the mains supply. Use an
earthing strap to earth the ventilator.
