SM ALFOplus - Page 40

38 MN.00273.E - 004
- Modulation 4QAM up to 1024QAM
- Number of settable RF channel depending on RF band and capacity
- Tuning frequency step 250 KHz
- Tx/Rx frequency spacing see Tab.3
- Noise figure see Tab.5
Tab.5 - Noise figure
42
GHz
Radio Nominal RSL
Threshold (dBm)
Physical Mode
Channel bandwidth
MHz
4SQAM 4QAM 16SQAM 16QAM 32QAM 64QAM 128QAM 256QAM 512QAM 1KQAM
7
BER=10
-6
-91.5 -89.0 -85.5 -82.5 -80.5 -78.0 -74.5 -72.0 -69.0 -65.5
BER=10
-10
-89.5 -87.0 -83.5 -80.5 -78.5 -76.0 -72.5 -70.0 -67.0 -63.5
14
BER=10
-6
-90.5 -87.0 -83.5 -80.5 -78.5 -76.0 -72.5 -69.5 -66.5 -62.5
BER=10
-10
-88.5 -85.0 -81.5 -78.5 -76.5 -74.0 -70.5 -67.5 -64.5 -60.5
28
BER=10
-6
-87.5 -84.0 -80.5 -77.5 -76.0 -73.0 -70.0 -66.5 -64.0 -60.0
BER=10
-10
-85.5 -82.0 -78.5 -75.5 -74.0 -71.0 -68.0 -64.5 -62.0 -58.0
56
BER=10
-6
-84.5 -81.0 -77.5 -74.5 -72.5 -70.0 -67.0 -63.5 -61.0 -56.5
BER=10
-10
-82.5 -79.0 -75.5 -72.5 -70.5 -68.0 -65.0 -61.5 -59.0 -54.5
Radio Guaranteed RSL
Threshold (dBm)
Physical Mode
Channel bandwidth
MHz
4SQAM 4QAM 16SQAM 16QAM 32QAM 64QAM 128QAM 256QAM 512QAM 1KQAM
7
BER=10
-6
-89.5 -87.0 -83.5 -80.5 -78.5 -76.0 -72.5 -70.0 -67.0 -63.5
BER=10
-10
-87.5 -85.0 -81.5 78.5 76.5 -74.0 -70.5 -68.0 -65.0 -61.5
14
BER=10
-6
-88.5 -85.0 -81.5 -78.5 -76.5 -74.0 -70.5 -67.5 -64.5 -60.5
BER=10
-10
-86.5 -83.0 -79.5 -76.5 -74.5 -72.0 -68.5 -65.5 -62.5 -58.5
28
BER=10
-6
-85.5 -82.0 -78.5 -75.5 -74.0 -71.0 -68.0 -64.5 -62.0 -58.0
BER=10
-10
-83.5 -80.0 -76.5 -73.5 -72.0 -69.0 -66.0 -62.5 -60.0 -56.0
56
BER=10
-6
-82.5 -79.0 -75.5 -72.5 -70.5 -68.0 -65.0 -61.5 -59.0 54.5
BER=10
-10
-80.5 -77.0 -73.5 -70.5 -68.5 -66.0 -63.0 -59.5 -57.0 -52.5
Frequency Band (GHz) Noise Figure (dB)
66
76
11 6.5
13 6.5
15 6.5
17 8
18 7
23 7
26 8.5
