Mount the sensor on a vertical exterior surface below an overhang. Choose a location
protected from direct sunlight and exposure to excessive moisture. Follow the same wiring
procedures as installing an indoor sensor.
TEMPERATURE SENSOR CALIBRATION CHART
REMOTE OUTDOOR SENSOR INSTALLATION
Temperature Resistance Temperature Resistance
(°C) (kÙ) (?C) (kÙ)
0 34.6 21 11.9
5 26.1 26 9.4
10 19.9 32 7.4
15 15.3 37 5.9
NTC type 3 sensor - 10K @ 25° CÙ
