You can connect your document camera directly to an external display to enable the following
functions:
l Use Camera mode to view the camera image in full-screen on the external display.
l Use Playback mode to view a full-screen slide show on the external display.
I M P O R T A N T
To use your document camera with SMARTNotebook software you need to connect your
document camera to a computer.
Setting the TV/VGA switch
The TV/VGA switch determines the display output selection. Set it to VGA (right) when using a
VGA or DVI connection for a signal output. Set it to TV (left) when using an RCA connection for
a composite output.
Connecting your document camera to a monitor or a projector
In this configuration your document camera is connected to your external display device with a VGA
cable.
To connect your document camera to a monitor or a projector
1. Complete the basic connection steps (see page 12).
I M P O R T A N T
Make sure the TV/VGA switch is set to VGA .
2. Connect a VGA cable to your document camera's VGA Out receptacle and your display
device's VGA In connector .
Connecting your document camera to a monitor or a projector with a DVI
interface
In this configuration your document camera is connected to your external display device with a DVI
cable (not supplied).
