To connect the microscope to a projector or a display
1.
Press the button on the control panel, and then select the tab.
2.
Use the button on the control panel to select MODE, and then press the button on the
control panel.
3.
Use the button on the control panel to select , and then press the button on the
control panel.
4.
Press the button on the control panel to close the menu.
5. Connect the other end of the VGA cable to the VGA In connector on your projector or display.
6.
Set the VGA/TV switch on the right-side connection panel to VGA .
Switching between VGA, DVI and composite output
If you’re using a projector or a computer display with a VGA or a DVI cable, set your document
camera to the VGA mode. If you’re using a television with the composite video cable, set your
document camera to the TV mode
To set your document camera to the VGA mode
Set the VGA/TV switch on the right-side connection panel to VGA .
To set your document camera to the TV mode
Set the VGA/TV switch on the right-side connection panel to TV .
Connecting your document camera to an external microphone
You can connect an external microphone to your document camera.
N O T E S
l The built-in microphone on the control panel is disabled when an external microphone is
connected.
l The audio is in monophonic sound.
