SMART 450 - Shooting Area, Overhead Light and Anti-Glare Sheet; Connecting Your Document Camera to Speakers; Shooting Area

To connect an external microphone to your document camera
Connect the microphone's cable to the microphone on your document camera's left-side
connection panel.
Connecting your document camera to speakers
You can connect speakers to your document camera. Only audio from the video playback is
supported.
C A U T I O N
Turn the volume down to prevent hearing damage when using earphones.
To connect speakers
Connect the speakers’ 3.5 mm cable to the speaker receptacle on your document camera's left-
side connection panel.
Shooting area, overhead light and anti-glare
sheet
Shooting area
The shooting area can view a maximum area of 15 3/4" × 11 3/4" (40 cm × 30 cm).
To rotate the image
1.
Press the button on the control panel.
2.
Press the button on the control panel, and then select .
3.
Press the button on the control panel.
4.
Press the button on the control panel, and then select ROTATE.
5.
Press the button on the control panel.
6.
Select rotation range, and then press the button on the control panel.
7.
Press the button on the control panel to close the menu.
C H A P T E R 2
Setting up your SMARTDocumentCamera
19
