Useful information
The engine compartment in the smart is
located at the rear, below the boot. Service
fluid reservoirs are located under the ser-
vice cover at the front.
When working on the vehicle, always com-
ply with all safety regulations. Always
have work in the engine compartment car-
ried out at a qualified specialist workshop.
Removing/fitting the subwoofer
Removing the subwoofer
X
Release quick-release fastener : in the
direction of the arrow.
X
Reach into the recess on the quick-
release fastener.
X
Detach, tilt and pull the subwoofer to the
right.
X
Pull out the connector.
Fitting the subwoofer
X
Insert the connector.
X
Place the subwoofer at the base of the
side trim.
X
Turn quick-release fastener : upwards.
X
Press the bracket into the recess in side
trim ;.
X
Turn quick-release fastener : clock-
wise.
Opening and closing the service cover
Please note
G
WARNING
If the service cover is not locked, it may
come loose during driving and block your
view or endanger other road users. There
is a risk of an accident and injury.
Therefore, make sure that the service
cover is locked before driving off.
G
WARNING
If the windscreen wipers start to move
when the service cover is open, you could
become caught up in the wiper rods.
There is a risk of injury.
Always switch off the windscreen wipers
and the ignition before you open the ser-
vice cover.
!
To ensure unhindered air intake, com-
pletely remove any dirt or snow from the
ventilation slots above the service cover.
The vehicle must be secured against rolling
away.
On vehicles with a lockable service cover,
the service cover must be unlocked before it
is opened.
158
Opening and closing the service cover
>> Maintenance and care.
