MGC300 Genset Controller User Manual
MGC300 Genset Controller Version 1.1 2020-01-04 Page 10 of 27
4.4 DISPLAY DISCRIPTION
Mains: Phase Voltage L1, Frequency F Mains: Phase Voltage L2, Frequency F
Mains: Phase Voltage L3, Frequency F Gen: Phase Voltage L1, Curent IA
Gen: Phase Voltage L2, Current IB Gen: Phase Voltage L3, Current IC
Mains: Line Voltage L12, Frequency F Mains: Line Voltage L23, Frequency F
Mains: Line Voltage L31, Frequency F Gen: Line Voltage L12, Frequency F
Gen: Line Voltage L23, Frequency F Gen: Line Voltage L31, Frequency F
Battery Voltage, Speed Fuel Level, Temp.
Active Power, Accumulated Running Time
NOTE1: When temp. and level sensor are not displayed, it means they are not used; when OFF is displayed, it means that
sensor is open.
