MGC300 Genset Controller User Manual
MGC300 Genset Controller Version 1.1 2020-01-04 Page 16 of 27
7 DEFINITION AND RANGE OF PARAMETERS
7.1 PARAMETER SETTING CONTENTS AND RANGE
Table 7 Controller Configuration Parameters
No.
Items
Parameter Range
Default
Description
P00
Mains Normal Delay
(0-3600)s
10
Check time duration for Mains voltage from
abnormal to normal or from normal to
abnormal to be used for ATS transfer.
P01
Mains Abnormal
Delay
(0-3600)s
5
P02
Mians Under Volt
Value
(30-6000)V
184
If the voltage sample is lower than it, Mains
under voltage is considered; When it is set
30V, under voltage signal shall not be
detected; return difference is 10V;
P03
Mains Over Volt
Value
(30-6000)V
276
If the voltage sample is higher than it, Mains
over voltage is considered; When it is set
60000V, overvoltage signal shall not be
detected; return difference is 10V;
P04
Mains Options
(0-1)
0
0: AMF 1: Display Only
P05
Start Delay
(0-3600)s
1
Time duration from mains abnormal or
remote start signal is active to genset
startup.
P06
Stop Delay
(0-3600)s
1
Time duration from mains normal or remote
start signal is deactivated to genset stop.
P07
Start Attempts
(1-10) times
3
It is maximum start attempts when starter
fails to start. When it reaches set attempts
controller shall send out start failure signal.
P08
Pre Heating
(0-300)s
0
Pre-heating plug pre-energization time
before starter is powered on;
P09
Cranking Time
(3-60)s
8
Time for starter to be energized every time.
P10
Crank Rest Time
(3-60)s
10
The waiting time before second power up
when engine start fails.
P11
Safety On Delay
(1-60)s
10
Alarms for low oil pressure, temp. high,
under speed, under frequency and under
voltage are deactivated.
P12
Start Idle Delay
(0-3600)s
0
Time for genset idle running at starting;
P13
Warming Up Time
(0-3600)s
10
Warming-up time before breaker close after
high speed running for genset.
P14
Cooling Time
(3-3600)s
10
Radiating time before genset stop after
genset is unloaded.
P15
Stop Idle Delay
(0-3600)s
0
Time for genset idle running at stopping;
P16
ETS Solenoid Hold
(0-120)s
20
The time for Stop electromagnet to be
energized before genset stop.
P17
Wait for Stop
(0-120)s
0
Time from idle delay to complete stop when
ETS stop output is set to 0; when the output
time is not 0s; it's time from ETS stop end to
