MGC300 Genset Controller User Manual
MGC300 Genset Controller Version 1.1 2020-01-04 Page 6 of 27
3 SPECIFICATION
Table 2 Technical Parameters
Items
Contents
Working Voltage
DC (8.0-35.0)V continous
Overall Consumption
≤1.4W (Standby mode: ≤0.35W, 0W=low power consumption);
AC Volt Input:
3 phase 4 wire
3 phase 3 wire
Single phase 2 wire
2 phase 3 wire
30V AC - 360V AC (ph-N)
30V AC - 620V AC (ph-ph)
15V AC - 360V AC (ph-N)
15V AC - 360V AC (ph-N)
Alternator Frequency
50Hz/60Hz
Starter Relay Output
7A 24V DC power supply
Fuel Relay Output
7A 24V DC power supply
Flexible Relay Output 1
7A 250V AC volt free output
Flexible Relay Output 2
7A 250V AC volt free output
Overall Dimensions
126mm x 106mm x 46.5mm
Panel Cutout
111mm x 91mm
CT Secondary Current
Rated: 62.5mA
Working Condition
Temperature:(-25~+70)°C
Humidity:(20~93)%RH
Storage Condition
Temperature:(-30~+80)°C
Protection Level
Front panel IP65
Insulation
Apply AC2.2kV voltage between high voltage terminal and low voltage
terminal and the leakage current is not more than 3mA within 1min.
Weight
0.27kg
