MGC300 Genset Controller User Manual
MGC300 Genset Controller Version 1.1 2020-01-04 Page 18 of 27
No.
Items
Parameter Range
Default
Description
the temp. high alarm signal of input port);
P29
Level Low Warning
Value
(0-200)%
50
When level is under this value for 10s, level
low warning is issued (only warning, not
stop);
P30
Battery Over
Voltage Warning
(12-40)V
33.0
When battery voltage is higher than this
value for 20s, battery voltage abnormal
signal is issued; (only warning, not stop)
P31
Battery Under
Voltage Warning
(4-30)V
8.0
When battery voltage is lower than this value
for 20s, battery voltage abnormal signal is
issued; (only warning, not stop)
P32
CT Ratio
500A/62.5mA
500
CT ratio for externally connected CT;
P33
Full Load Current
(5-6000)A
500
Rated current of genset; used for full load
current calculation;
P34
Over Current %
(50-130)%
120
When full load current is higher than this,
over current delay started;
P35
Over Current Delay
(0-3600)s
60
Finite over current delay; when load current
is over the pre-set value for pre-set time,
over current is considered; when delay is 0s;
it only gives warning, not stop;
P36
Over Current Action
(0-2)
0
0: Warning 1: Shutdown
2: Cooling Shutdown
P37
Digital Output 1 Set
(0-9)
5
See Table 8 for detailed output contents;
P38
Digital Output 2 Set
(0-9)
6
See Table 8 for detailed output contents;
P39
Fuel Output Time
(1-60)s
1
Fuel output time for genset start;
P40
Power On Mode
Selection
(0-2)
0
0: Stop
1：Manual Mode
2：Auto Mode
P41
Module Address
(1-254)
1
Communication address
P42
Password
(0-9999)
318
Controller password.
P43
Disconnection Gen.
Frequency
(0.0-30.0)Hz
14.0
In the starting process when gen frequency
exceeds this value, it is considered that start
is successful and starter will be
disconnected.
P44
AC System
(0-3)
0
0: 3P4W 1: 2P3W
2: 1P2W 3: 3P3W
P45
Temp Sensor Types
(0-12)
8
See Table 10 for Temp. sensor type;
P46
Level Sensor
Selection
(0-5)
3
See Table 10 for level sensor type;
P47
Input 1 Set
(0-8)
4
See Table 9 for input contents;
P48
Digital Input 1 Delay
(0-20.0)s
2.0
Digital input acts when input is delaying;
P49
Low Consumption
(0-180)s
0
Low power consumption time setting
