HFC6100LT Fan Controller User Manual Page 17 of 24
No.
Item
Range
Default
Remark
97
Aux. Input 10 Delay
(0-20.0)s
2.0
98
Aux. Input 11 Setting
(0-35)
15
Factory default: 11#fan running input.
99
Aux. Input 11 Active
(0-1)
0
Factory default: closed
100
Aux. Input 11 Delay
(0-20.0)s
2.0
101
Aux. Input 12 Setting
(0-35)
16
Factory default: 12#fan running input.
102
Aux. Input 12 Active
(0-1)
0
Factory default: closed
103
Aux. Input 12 Delay
(0-20.0)s
2.0
104
Aux. Input 13 Setting
(0-35)
0
Factory default: Not used.
Refer to Table 10
105
Aux. Input 13 Active
(0-1)
0
Factory default: closed
106
Aux. Input13 Delay
(0-20.0)s
2.0
107
Aux. Input 14 Setting
(0-35)
0
Factory default: Not used.
Refer to Table 10
108
Aux. Input 14 Active
(0-1)
0
Factory default: closed
109
Aux. Input 14 Delay
(0-20.0)s
2.0
110
Aux. Input 15 Setting
(0-35)
0
Factory default: Not used.
Refer to Table 10
111
Aux. Input 15 Active
(0-1)
0
Factory default: closed
112
Aux. Input 15 Delay
(0-20.0)s
2.0
113
Aux. Input 16 Setting
(0-35)
0
Factory default: Not used.
Refer to Table 10
114
Aux. Input 16 Active
(0-1)
0
Factory default: closed
115
Aux. Input 16 Delay
(0-20.0)s
2.0
116
Aux. Input 17 Setting
(0-35)
0
Factory default: Not used.
Refer to Table 10
117
Aux. Input 17 Active
(0-1)
0
Factory default: closed
118
Aux. Input 17 Delay
(0-20.0)s
2.0
119
Aux. Input 18 Setting
(0-35)
0
Factory default: Not used.
Refer to Table 10
120
Aux. Input 18 Active
(0-1)
0
Factory default: closed
121
Aux. Input 18 Delay
(0-20.0)s
2.0
122
Power-on Mode Option
(0-1)
1
0: Manual mode;
1: Auto mode.
123
Controller Address
(1-254)
1
The communication address of controller.
124
Password Setting
0-9999
318
The password of the module.
125
1#PWM Output Sensor
(0-4)
1
Factory default: sensor 1 temperature
126
1#PWM Output
Minimum
(0-100)%
0
The PWM1 minimum duty ratio.
127
1#PWM Output Mini.
Temp.
(0-300)°C
40
The corresponding temperature value of
PWM1 mini. duty ratio.
128
1#PWM Output
Maximum
(0-100) %
100
The PWM1 maximum duty ratio.
129
1#PWM Output Max.
Temp.
(0-300)°C
90
The corresponding temperature value of
PWM1 max. duty ratio.
