Smartgen HFC6100LT User Manual

HFC6100LT Fan Controller User Manual Page 18 of 24
No.
Item
Range
Default
Remark
130
2#PWM Output Sensor
(0-4)
2
Factory default: sensor 2 temperature
131
2#PWM Output
Minimum
(0-100)%
0
The PWM2 minimum duty ratio.
132
2#PWM Output Mini.
Temp.
(0-300)°C
40
The corresponding temperature value of
PWM2 mini. duty ratio.
133
2#PWM Output
Maximum
(0-100)%
100
The PWM2 maximum duty ratio.
134
2#PWM Output Max.
Temp.
(0-300)°C
90
The corresponding temperature value of
PWM2 max. duty ratio.
135
3#PWM Output Sensor
(0-4)
3
Factory default: sensor 3 temperature
136
3#PWM Output
Minimum
(0-100)%
0
The PWM3 minimum duty ratio.
137
3#PWM Output Mini.
Temp.
(0-300)°C
40
The corresponding temperature value of
PWM3 mini. duty ratio.
138
3#PWM Output
Maximum
(0-100)%
100
The PWM3 maximum duty ratio.
139
3#PWM Output Max.
Temp.
(0-300)°C
90
The corresponding temperature value of
PWM3 max. duty ratio.
140
4PWM Output Sensor
(0-4)
4
Factory default: sensor 4 temperature
141
4#PWM Output
Minimum
(0-100)%
0
The PWM4 minimum duty ratio.
142
4#PWM Output Mini.
Temp.
(0-300)°C
40
The corresponding temperature value of
PWM4 mini. duty ratio.
143
4#PWM Output
Maximum
(0-100)%
100
The PWM4 maximum duty ratio.
144
4#PWM Output Max.
Temp.
(0-300)°C
90
The corresponding temperature value of
PWM4 max. duty ratio.
145
Start Interface Delay
(0-360.0)s
0
If set as 0, the start interface is disabled.
146
Date Setting
Set the date of the module.
147
PWM1 Manual Output
Setting
(0-100)%
0
When the controller switches to manual
mode, the default output PWM value.
148
PWM2 Manual Output
Setting
(0-100)%
0
149
PWM3 Manual Output
Setting
(0-100)%
0
150
PWM4 Manual Output
Setting
(0-100)%
0
151
Fan Running Detection
Delay
(0-3600)s
5
After controlling the fan output, detect the
time of the fan operation input.
When detects delay is 0s, fun operation
input is not detected.
152
Fan Off Delay
(0-3600)s
5
In auto mode, after the unit operation
input is inactive, all the output
disconnected delay time.
