HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 11 of 39
3) When “Stop Delay” is over, genset enters into “Cooling Delay”. Closing relay is
disconnected. After switch “Transfer Rest Delay”, closing relay is outputting, mains is
taking load, generator indicator eliminates while mains indicator illuminates.
4) When entering “Stop Idle Delay”, idle relay is energized to output. (If configured).
5) When entering “ETS Delay”, ETS relay is energized to output, fuel relay output is
disconnected.
6) When entering “Genset at Rest”, genset will automatically judge if it has stopped.
7) When genset has stopped, enter into standby mode; if genset failed to stop,
controller will alarm (“Fail to Stop” alarm will be displayed in LCD).
