HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 19 of 39
No. Function Cable Size Description
34 Mains N1 Input 1.0mm
2
Connect to mains N-wire, HGM6110UC
without.
35
RS485 Common
Ground
/
Impedance-120Ω shielding wire is
recommended, its single-end connect
with ground.
36 RS485 - 0.5mm
2
37 RS485+ 0.5mm
2
38 Configurable Input 4 1.0mm
2
Ground connected is
active (B-)
Reference
table 3
39 Configurable Input 5 1.0mm
2
Ground connected is
active (B-)
40 Sensor Common 1.0mm
2
Sensor common port
Note: LINK ports in controller rear panel are programmable parameter ports, user
can directly program SG72 via PC.
