7.4 SENSOR SELECTION (TABLE 4)
No. Items Content Description
1
Temperature
Sensor
0 Not used
1 Defined Resistance Type
2 VDO
3 SGH(Huanghe sensor)
4SGD(DongKang sensor)
5 CURTIS
6 DATCON
7 VOLVO-EC
8 SGX
9 Reserved
Defined input resistance
range is 0Ω~6000Ω, factory
default is SGX sensor.
2
Pressure
Sensor
0 Not used
1 Defined Resistance Type
2 VDO 10Bar
3 SGH(Huanghe sensor)
4 SGD(DongKang sensor)
5 CURTIS
6 DATCON 10Bar
7 VOLVO-EC
8 SGX
9 Reserved
Defined input resistance
range is 0Ω~6000Ω, factory
default is SGX sensor.
3
Fuel Level
Sensor
0 Not used
1 Defined Resistance Type
2 SGH
3 SGD
4 Reserved 1
5 Reserved 2
Defined input resistance
range is 0~6000Ω, factory
default is SGD sensor.
