HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 27 of 39
7.3 PROGRAMMABLE INPUT 1-5 TABLE (ALL IS ACTIVE WHEN
CONNECT TO GROUND (B-) (TABLE 3)
No. Items Description
0 Not Used
1 High Temp. Alarm If the signal is active after safety run on delay over,
genset will immediately alarm to shutdown.
2 Low OP Alarm
3 Auxiliary Alarm
Only warn, not shutdown.
4 Aux. Shutdown Alarm
If the signal is active, genset will immediately
alarm to shutdown.
5 Coolant To Stop
During engine running and the input is active, if
high temperature occurs, controller will stop after
high speed cooling; when the input is disabled,
controller will stop immediately.
6 Gens Closed Input
7 Mains Closed Input
8 High Temp. Inhibit
When it is active, high oil temperature stop is
inhibited. See Note1 for more information.
9 Low Oil Pressure Inhibit
When it is active, low oil pressure stop is inhibited.
See Note2 for more information.
10 Remote Start Input
11 Low Fuel Level Warn
12 Low Water Level Warn
13
Low Fuel Level
Shutdown
14
Low Water Level
Shutdown
15 Auto Start Inhibit
In Auto Mode, when the input is active, no matter
mains normal or not, genset won’t start. If genset
is in normal running, stop process won’t be
executed. When input is disabled, genset will
automatically start or stop judging by mains
normal or not.
To Next Page
