HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 29 of 39
7.5 CONDITIONS OF CRANK DISCONNECT (TABLE 5)
No. Content
0 Magnetic pickup sensor
1 Generator
2 Magnetic pickup sensor + Generator
3 Magnetic pickup sensor + Oil pressure
4 Generator + Oil pressure
5 Generator + Magnetic pickup sensor + Oil pressure
1) There are 3 kinds of crank disconnect conditions. Magnetic pickup sensor and
generator can be used alone. Oil pressure must be used with magnetic pickup
sensor and the generator, in order to make the starter and the engine disconnect as
soon as possible.
2) Magnetic pickup sensor is installed in the engine for testing flywheel teeth.
3) When choosing magnetic pickup sensor, ensure the number of flywheel teeth is
same as the pre-set, otherwise over or under speed shutdown may appear.
4) If generator has no magnetic pickup sensor, don't choose corresponding item;
otherwise Fail to Start or Loss of Speed Signal shutdown will occur.
5) If the generator has no oil pressure sensor, don't choose corresponding item.
6) If generator has not been selected, controller will not measure and display the
relative parameters (can be applied to the pump set); if magnetic pickup sensor has
not been selected, the rotating speed will calculated by the generating AC signal.
