7 PARAMETER RANGE AND DEFINITION
7.1 PARAMETER CONTENT AND RANGE TABLE (TABLE 1)
No. Items Range Default Description
1
Mains Normal
Delay
(0-3600)s 10
The delay from abnormal to
normal or from normal to
abnormal. It used for ATS
(automatic transfer switch)
control.
2
Mains Abnormal
Delay
(0-3600)s 5
3
Mains Under
Voltage
(30-620)V 184
When mains voltage is under
the point, mains under voltage
active. When the value is 30,
mains under voltage disabled.
4
Mains Over
Voltage
(30-620)V 276
When mains voltage is
greater than the point, mains
over voltage active. When the
point is 620V, mains over
voltage disabled.
5
Transfer Rest
Time
(0-99.9)s 1.0
It’s the delay from mains open
to generator closed or from
generator open to mains
closed.
6 Start Delay (0-3600)s 1
Time from mains abnormal or
remote start signal is active to
start genset.
7 Stop Delay (0-3600)s 1
Time from mains normal or
remote start signal is inactive
to genset stop.
8 Start Times (1-10) times 3
When engine start failure, it’s
the maximum cranking times.
When setting crank times out,
controller send start fail
signal.
9 Preheat Time (0-300)s 0
Time of pre-powering heat
plug before starter is powered
up.
10 Crank Time (3-60)s 8
Time of starter power up each
time.
11 Crank Rest Time (3-60)s 10
The second waiting time
before power up when engine
start fail.
12
Safe Running
Time
(1-60)s 10
Alarm for low oil pressure,
high temp, under speed,
under frequency /voltage,
charge fail are all inactive.
To Next Page
