HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 21 of 39
No. Items Range Default Description
13 Start Idle Time (0-3600)s 0
Idle running time of genset
when starting.
14 Warming Up Time (0-3600)s 10
Warming time between
genset switch on and high
speed running.
15 Coolant Time (3-3600)s 10
Time for cooling before
stopping.
16 Stop Idle Time (0-3600)s 0
Idle running time when genset
stop.
17 ETS Time (0-120)s 20
Stop electromagnet’s power
on time when genset is
stopping.
18 Over Stop Delay (0-120)s 0
If “ETS output time” set as 0,
it is the time from end of idle
delay to gen-set at rest; if not
0, it is from end of ETS
solenoid delay to gen-set at
rest
19
Switch Close
Delay
(0-10)s 5.0
Mains’ or generator’s switch
closing pulse width, when it is
0, output is continuous.
20 Flywheel Teeth (10-300) 118
Number of flywheel teeth, it
can detect disconnection
conditions and engine speed.
21
Genset Abnormal
Delay
(0-20.0)s 10.0
Over or under volt alarm
delay
22
Genset Over
Voltage shutdown
(30-620)V 264
When genset voltage is over
the point, generator over
voltage is active. When the
point is 620V, generator over
voltage is disabled.
23
Genset Under
Voltage
(30-620)V 196
When generator voltage is
under the point, generator
under voltage is active. When
the point is 30V, generator
under voltage is disabled.
24
Under Speed
shutdown
(0-6000)RPM 1200
When the engine speed is
under the point for 10s,
shutdown alarm signal is sent
out.
25
Over Speed
shutdown
(0-6000)RPM 1710
When the engine speed is
over the point for 2s,
shutdown alarm signal is sent.
