HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 22 of 39
No. Items Range Default Description
26
Under Frequency
shutdown
(0-75.0)Hz 45.0
When generator frequency is
lower than the point (not
equal to 0) for 10s, shutdown
alarm signal is sent.
27
Over Frequency
shutdown
(0-75.0)Hz 57.0
When generator’s frequency
is over the point and
continues for 2s, generator
over frequency is active.
28
High Temperature
shutdown
(80-140)ºC 98
When engine temperature
sensor value is over this
point, it sends out high temp.
alarm. When the value is 140,
warning alarm won’t be sent.
(only suited for temperature
sensor, except for high temp.
pressure alarm signal
inputted by programmable
input port )
29
Low Oil Pressure
shutdown
(0-400)kPa 103
When engine oil pressure
sensor value is under this
point, Low Oil Pressure alarm
is sending out. When the
value is 0, warning alarm
won’t be sent. (only suited for
oil pressure sensor, except for
low oil pressure alarm signal
inputted by programmable
input port)
30 Low Fuel Level (0-100)% 10
When fuel level sensor value
under this point and remains
for 10s, genset send out
warning alarm, only warn but
not shutdown.
31
Loss Of Speed
Signal Delay
(0-20.0)s 5.0
When the delay setting as 0s,
it only warn but not shutdown
32 Charge Failure (0-30)V 6.0
During generator is running,
when charge alternator
WL/D+ voltage is under this
point and remain for 5s,
generator will warning alarm
and shutdown.
33
Battery Over
Voltage
(12-40)V 33.0
When generator battery
voltage is over the point and
remains for 20s, battery over
voltage signal is active. it only
warn but not shutdown
