Smartgen HGM6120U

HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 23 of 39
No. Items Range Default Description
34
Battery Under
Voltage
(4-30)V 8.0
When generator battery
voltage is under the point and
remains for 20s, battery under
voltage signal is active. it only
warn but not shutdown
35 CT Rate (5-6000)/5 500 Current transformer rate
36 Full Load Current (5-6000)A 500
Rated current of generator,
used for calculating over load
current.
37
Over Current
Percentage
(50-130)% 120
When load current is over the
point, the over current delay is
initiated.
38
Over Current
Delay
(0-3600)s 1296
When load current is over the
point, over current signal is
sent. When the delay is 0,
only warn but not shutdown.
39 Fuel Pump Open (0-100)% 25
When the fuel level lower than
the set value for 10s, send a
signal to open fuel pump.
40 Fuel Pump Close (0-100)% 80
When the fuel level higher
than the set value for 10s,
send a signal to close fuel
pump.
41 Aux. Output 1 (0-17) 2
Factory default: Energized to
stop
42 Aux. Output 2 (0-17) 3 Factory default: Idle control
43 Aux. Output 3 (0-17) 5 Factory default: Gens closed
44 Aux. Output 4 (0-17) 6 Factory default: Mains closed
45 Aux. Input 1 (0-15) 1
Factory default: High
temperature alarm
46
Aux. Input 1
Active
(0-1) 0 Factory default: close
47
Aux. Input 1
Delay
(0-20.0)s 2.0
48 Aux. Input 2 (0-15) 2
Factory default: Low oil
pressure alarm
49
Aux. Input 2
Active
(0-1) 0 Factory default: close
50
Aux. Input 2
Delay
(0-20.0)s 2.0
51 Aux. Input 3 (0-15) 10
Factory default: Remote start
input
52
Aux. Input 3
Active
(0-1) 0 Factory default: close
