HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 24 of 39
No. Items Range Default Description
53
Aux. Input 3
Delay
(0-20.0)s 2.0
54 Aux. Input 4 (0-15) 11
Factory default: Low fuel level
warn
55
Aux. Input 4
Active
(0-1) 0 Factory default: close
56
Aux. Input 4
Delay
(0-20.0)s 2.0
57 Aux. Input 5 (0-15) 12
Factory default: Low coolant
level warn
58
Aux. Input 5
Active
(0-1) 0 Factory default: close
59
Aux. Input 5
Delay
(0-20.0)s 2.0
60
Power Mode
Select
(0-2) 0
0: Stop Mode; 1: Manual
Mode; 2: Auto Mode
61 Module Address (1-254) 1 The address of controller.
62 Password (0-9999) 1234
63
Crank
Disconnect
Condition
(0-5) 2
Conditions of disconnecting
starter (generator, magnetic
pickup sensor, oil pressure),
Each condition can be used
alone and simultaneously to
separating the start motor and
genset as soon as possible.
64 Engine Speed (0-3000)RPM 360
When engine speed is over
this point, starter will
disconnect.
65
Engine
Frequency
(10-30)Hz 14
When generator frequency is
over this point, starter will
disconnect.
66
Engine Oil
Pressure
(0-400)kPa 200
When engine oil pressure is
over this point, starter will
disconnect.
67
High Temp. Inhibit
Select
(0-1) 0
Default: when temperature is
overheat, the genset alarm
and shutdown. Note1
68
Low OP Inhibit
Select
(0-1) 0
Default: when oil pressure is
too low, it alarm and
shutdown. Note2
69
Voltage Input
Select
(0-3) 0
0: 3P4W 1: 2P3W
2: 1P2W 3: 3P3W
70
Temp. Sensor
Select
(0-9) 8 SGX
