No. Items Range Default Description
71
Pressure Sensor
Select
(0-9) 8 SGX
72
Liquid Level
Sensor Select
(0-5) 3 SGD
73 Poles Number (2-32) 4
Number of magnetic poles,
used for calculating rotating
speed of generator without
speed sensor.
74
Temp. Sensor
Open Circuit
Action
(0-2) 1
0: Indication; 1: Warning;
2: Shutdown
75
Oil Pressure
Sensor Open
Circuit Action
(0-2) 1
76 Maintenance time (0-5000)h 30
It is used for setting genset
maintenance interval.
77
Maintenance time
out action
(0-2) 0
0 Not used； 1 Warning；
2 Shutdown
When maintenance action
type is set as“Not used”
maintenance alarm reset.
78
Defined Sensor
Curve
(0-2)
0:Defined temperature sensor
1: Defined pressure sensor
2: Defined liquid level sensor
Select the sensor, input
corresponding 8 values.
Note1, if select high temperature inhibit, or set programmable input as High
Temperature Inhibit ( this input is active), when temperature is higher than pre-setting
threshold or high temperature alarm is activated, controller sends warning signal only
and not shutdown.
Note2, if select low oil pressure inhibit, or set programmable input as Low Oil Pressure
Inhibit ( this input is active), when low oil pressure is lower than pre-setting threshold or
low oil pressure alarm is activated, controller sends warning signal only and not
shutdown.
