HGM6100U Series Automatic Control Module
HGM6100U Automatic Genset Controller ISSUE 2014-10-28 Version 1.2 Page 38 of 39
Note: A. ICOM must connect to battery cathode of the controller.
B. When there is load current, open circuit is inhibited in the CT secondary side.
5) Dielectric Strength test
When the controller has been installed in the control panel, during the test please
disconnect all the terminals in case high voltage damages the controller.
