Smartgen HGM7100N Series User Manual

HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 14 of 47
No.
Type
Description
18
Breaker Switch Fail
When controller detects that the breaker is fail to close/open (when the
warning is enabled), it will initiate a warning alarm.
19
Temp. Sensor Open
Circuit
When controller detects that the temperature sensor is open circuit and
action select “Warning”, it will initiate a warning alarm.
20
High Temp. Warning
When controller detects that the temperature is higher than the pre-set
value, it will initiate a warning alarm.
21
Low Temp. Warning
When controller detects that the temperature is lower than the pre-set
value, it will initiate a warning alarm.
22
Oil Pressure Sensor
Open Circuit
When controller detects that sensor is open circuit, and action type
select “Warning”, it will initiate a warning alarm.
23
Low Oil Pressure
Warning
When controller detects that the oil pressure value falls below the
pre-set value, it will initiate a warning alarm.
24
Level Sensor Open
Circuit
When controller detects that sensor is open circuit, and action type
select “Warning”, it will initiate a warning alarm.
25
Low Level Warning
When controller detects that the liquid level value falls below the
pre-set value, it will initiate a warning alarm.
26
Config. Sensor 1 Open
Circuit
When controller detects that sensor is open circuit, and action type is
select “Warning”, it will initiate a warning alarm.
27
Config. Sensor 1 High
When controller detects that the sensor value exceeds the pre-set
upper limit warning value, it will initiate a warning alarm.
28
Config. Sensor 1 Low
When controller detects that the sensor value falls below the pre-set
lower limit warning value, it will initiate a warning alarm.
29
Config. Sensor 2 Open
Circuit
When controller detects that sensor is open circuit, and action type is
select “Warning”, it will initiate a warning alarm.
30
Config. Sensor 2 High
When controller detects that the sensor value exceeds the pre-set
upper limit warning value, it will initiate a warning alarm.
31
Config. Sensor 2 Low
When controller detects that the sensor value falls below the pre-set
lower limit warning value, it will initiate a warning alarm.
32
Input Warning
When digital input port configured as “Warning”, and it is active,
controller will initiate a warning alarm.
33
Cycle Start
Communication Fail
Warning
When two gensets, which during in cycle start status, fail to
communicate, controller will initiate a warning alarm.
