HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 30 of 47
8.2 DEFINITION CONTENT OF PROGRAMMABLE OUTPUT PORTS 1~6
Table 11 - Programmable Output Ports 1~6
No.
Type
Description
0
Not Used
1
Custom Period 1
For details of function description please see the following
contents.
2
Custom Period 2
3
Custom Period 3
4
Custom Period 4
5
Custom Period 5
6
Custom Period 6
7
Custom Combined 1
8
Custom Combined 2
9
Custom Combined 3
10
Custom Combined 4
11
Custom Combined 5
12
Custom Combined 6
13
Reserved
14
Reserved
15
Reserved
16
Reserved
17
Air Flap Control
Act at over speed shutdown and emergency stop; Engine air
inletting can be closed.
18
Audible Alarm
Act at warning, shutdown, electric trip; Annunciator can be
connected externally; When flexible input "Alarm Mute" is
active, it can be prohibited to output.
19
Louver Control
Act at generator start, disconnect after genset complete stop.
20
Fuel Pump Control
It is controlled by level sensor fuel pump controlling the upper
and lower limits.
21
Heater Control
It is controlled by temp sensor heating and controlling the
upper and lower limits.
22
Cooler Control
It is controlled by temp sensor cooling and controlling the
upper and lower limits.
23
Pre- fuel
Act in the period from crank to safety on time.
24
Excite Generator
Output in the crank process; output for 2s again if Gen
frequency is lost in high speed period.
25
Pre-lubricate Output
Act in the period from pre-heating to safety on time.
26
Remote PC Output
This port is controlled by communication (PC).
27
Reserved
28
Reserved
29
Close Generator
Control generator breaker to take load.
30
Open Breaker
Control generator breaker to take off load.
31
Close Mains
Control Mains breaker to take on load.
32
Reserved
