HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 31 of 47
No.
Type
Description
33
Starter Relay Output
34
Fuel Relay Output
Act at generator start, disconnect at waiting to stop.
35
Idle Control
Used for gensets with idle speed control; Pull in before crank,
disconnect at entering warming up period; Pull in at stop idle
process, and disconnect at genset complete stop.
36
Raise Speed
Act in the period of warming up.
37
Drop Speed
Act in the period of stop idle and wait to stop running time.
38
ETS Control
Used for engines with ETS electromagnet. Close when stop idle
is over and open when pre-set “ETS delay” is over.
39
Pulse Drop Speed
40
Reserved
41
Reserved
42
Pulse Raise Speed
43
Crank Success
Close when a successful start signal is detected.
44
Generator OK
Act when generating is normal.
45
Generator Available
Act in period of generator ok to hi-speed cooling.
46
Mains OK
Act when Mains is normal.
47
Loading Speed Output
48
Common Alarm
Act at genset common warning, common shutdown, common
trips alarm.
49
Common Electrical Trip and
Stop
Act when common trip and stop alarm occurs.
50
Common Shutdown
Act when common shutdown alarm occurs.
51
Common Trip Alarm
Act when common trips alarm occurs.
52
Common Warning Alarm
Act when common warning alarm occurs.
53
Reserved
54
Battery High Voltage
Act when battery’s over voltage warning alarm occurs.
55
Battery Low Voltage
Act when battery’s low voltage warning alarm occurs.
56
Charge Alt Fail
Act when charge failure warning alarm occurs.
57
Reserved
58
Reserved
59
Reserved
60
ECU Warning Alarm
Indicate ECU sends a warning signal.
61
ECU Shutdown Alarm
Indicate ECU sends a shutdown signal.
62
Reserved
63
Reserved
64
Reserved
65
Reserved
66
Reserved
67
Reserved
68
Reserved
69
Digital Input 1 Active
Act when input port 1 is active
70
Digital Input 2 Active
Act when input port 2 is active
