HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 32 of 47
No.
Type
Description
71
Digital Input 3 Active
Act when input port 3 is active
72
Digital Input 4 Active
Act when input port 4 is active
73
Digital Input 5 Active
Act when input port 5 is active
74
Digital Input 6 Active
Act when input port 6 is active
75
Digital Input 7 Active
Act when input port 7 is active
76-
98
Reserved
99
Emergency Stop Alarm
Act when emergency stop alarm occurs.
100
Failed to Start Alarm
Act when failed start alarm occurs.
101
Failed to Stop Alarm
Act when failed stop alarm occurs.
102
Under Speed Warning
Act when under speed alarm occurs.
103
Under Speed Shutdown
Act when under speed shuts down.
104
Over Speed Warning
Act when over speed warns.
105
Over Speed Shutdown
Act when over speed shutdown alarm occurs.
106
Reserved
107
Reserved
108
Reserved
109
Gen. Over Freq Warning
Act when generator over frequency warning occurs.
110
Gen. Over Freq Shutdown
Act when generator over frequency shutdown alarm occurs.
111
Gen. Over Voltage Warning
Act when generator over voltage warning occurs.
112
Gen. Over Volt Shutdown
Act when generator over voltage shutdown occurs.
113
Gen. Under Frequency Warning
Act when generator low frequency warning occurs.
114
Gen. Under Frequency
Shutdown
Act when generator low frequency shutdown occurs.
115
Gen. Under Voltage Warning
Act when generator low voltage warning occurs.
116
Gen. Under Voltage Shutdown
Act when generator low voltage shutdown occurs.
117
Gen. Loss of Phase
Act when generator loss phase.
118
Gen. Reverse Phase
Act when generator reverse phase.
119
Reserved
120
Over Power Alarm
121
Reserved
122
Reverse Power
Act when controller detects generator has reverse power.
123
Over Current Alarm
Act when controller detects generator over current.
124
Reserved
125
Mains Inactive
126
Mains Over Frequency
127
Mains Over Voltage
128
Mains Under Frequency
129
Mains Under Voltage
130
Mains Reverse Phase
131
Mains Loss Of Phase
132-
138
Reserved
