HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 20 of 47
No.
Function
Cable Size
Remarks
38
Gen W-phase Voltage
Monitoring Input
1.0mm
2
Connected to W-phase output of genset (2A fuse
recommended).
39
Gen N2-line Input
1.0mm
2
Connected to N-line output of genset.
40
Mains R-phase Voltage
Monitoring Input
1.0mm
2
Connected to R-phase of mains (2A fuse recommended).
(HGM7110N without)
41
Mains S-phase voltage
monitoring input
1.0mm
2
Connected to S-phase of mains (2A fuse recommended).
(HGM7110N without)
42
Mains T-phase voltage
monitoring input
1.0mm
2
Connected to T-phase of mains (2A fuse recommended).
(HGM7110N without)
43
Mains line N1 Input
1.0mm
2
Connected to N-line of mains. (HGM7110N without)
44
RS485 Common Ground
0.5mm
2
120Ω shielded wire is recommended with single end
ground.
45
RS485-
0.5mm
2
46
RS485+
0.5mm
2
47
VOUT(+5V)
0.5mm
2
Output DC +5V.
NOTE: USB ports in controller rear panel are programmable parameter ports, user can directly configure the
controller via PC.
NOTE: ETHERNET port in controller rear panel is network monitoring port, user can directly monitor the controller
via PC.
