Smartgen HGM7100N Series User Manual

HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 36 of 47
No.
Items
Description
19
Remote Control Mode
Input
When input is active, all buttons on the panel except for
are inactive; LCD status page displays Remote
Mode.
20
Reserved
21
Inhibit Alarm Shutdown
All shutdown alarms are inhibited except for emergency stop
(sometimes called War Mode or Override Mode)
22
Instrument Mode
All outputs are inhibited in this mode.
23
Box Temp High Warning
24
Reset Maintenance Time
When input is active, controller will reset maintenance time and date
as pre-set values.
25
Low Level Shutdown
Connecting with sensor digital input.
26
High Temp Shutdown
Connecting with sensor digital input.
27
Low Oil Pressure
Shutdown
Connecting with sensor digital input.
28
Remote Start (On-load)
When input is active in auto mode, gen-set will be started
automatically, and then gen-set takes on load after normal running.
When input is inactive, gen-set will be stopped automatically.
29
Remote Start (Off-load)
When input is active in auto mode, gen-set will be started
automatically without taking load after normal running. When input
is inactive, gen-set will be stopped automatically.
30
Aux Manual Start
When input is active in manual mode, gen-set will be started
automatically. When input is inactive, gen-set will be stopped
automatically.
31
Simulate Up Key
32
Simulate Down Key
33
Simulate Stop Key
External Connecting a button to simulate key function on the panel.
34
Simulate Manual Key
35
Reserved
36
Simulate Auto Key
37
Simulate Start Key
38
Simulate Gen C/O Key
39
Simulate Mains C/O Key
40
Reserved
41
Reserved
42
Reserved
43
Simulate Set Key
44
Reserved
45
Simulate Mains OK
In auto mode, when input is active, it means Mains is Ok.
46
Simulate Mains Fail
In auto mode, when input is active, it means Mans is abnormal.
47
Alternative Config 1 Active
When input port is active, alternative configuration is available.
