HGM7100N GENSET CONTROLLER USER MANUAL
HGM7100N Genset Controller 2020-09-10 Version1.2 Page 44 of 47
Fig. 7 - Single Phase 2-Wire Connection Diagram
Fig. 8 - 2 Phase 3 Wire Connection Diagram
NOTE: Expand relay with high capacity in start and fuel output is recommended.
