HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 25 of 60
No.
Items
Range
Default
Description
9
Cooling Time
(0-3600)s
10
Cooling time before genset stop after genset
deloading.
10
Stop Idle Time
(0-3600)s
0
Running time for idling speed when genset
stops.
11
ETS Hold Time
(0-3600)s
20
Time for ETS energization before genset
stop.
12
Wait Stop Time
(0-3600)s
0
When “ETS Hold Time” is set 0, it is the time
after idle delay and before complete stop.
When “ETS Hold Time” is not 0, it is time
after ETS stop delay before complete stop.
13
After Stop Time
(0-3600)s
0
Time from genset stop to standby status.
Engine Setting
1
Engine Type
(0-39)
0
Default: conventional engine.
2
Flywheel Teeth
(1.0-300.0)
118
It is tooth number of the engine, which is
used for judging starter crank disconnect
conditions and inspecting engine speed. For
details please see the following installation
description.
3
Rated Speed
(0-6000)RPM
1500
Provide standard for judging over/under
speed and on-load speed.
4
Speed On-load
(0-100)%
90
The setting value is rated speed percentage.
The controller detects it while gen-set
prepares to take the load, if the speed is less
than the on-load speed, gen-set will not
enter normal operation period.
5
Speed Signal Loss
Delay
(0-3600)s
5
Time from the speed is detected 0 to action
confirmation.
6
Speed Signal Loss
Action
(0-1)
0
0: Warning; 1: Shutdown
7
Over Speed
Shutdown
(0-200)%
114
The setting value is the percentage of rated
speed, and delay value can be set.
8
Under Speed
Shutdown
(0-200)%
80
9
Over Speed
Warning
(0-200)%
110
The setting value is the percentage of rated
speed, return value and delay value can be
set.
10
Under Speed
Warning
(0-200)%
86
11
Battery Rated
Voltage
(0-60.0)V
24.0
Provide standard for judging battery
over/under voltage.
12
Battery High
Voltage Warning
(0-200)%
120
The setting value is the percentage of rated
voltage, return value and delay value can be
set.
13
Battery Low
Voltage Warning
(0-200)%
85
14
Charge Alt Fail
(0-60.0)V
8.0
If the voltage of charger D+(WL) is lower
than the setting value during gen-set normal
running, controller will initiate “Charge Alt
Fail” warning.
