HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 41 of 60
8.4 SELECTION OF SENSORS
Table 13 - Sensors Selection
No.
Description
Remark
1
Temperature Sensor
0 Not used
1 Custom resistor type curve
2 Custom current/voltage curve
3 VDO
4 CURTIS
5 VOLVO-EC
6 DATCON
7 SGX
8 SGD
9 SGH
10 PT100
11 SUZUKI
12-15 Reserved
Defined resistance’s
range is 0~6KΩ, default
is SGX sensor.
2
Oil Pressure (Pressure)
Sensor
0 Not used
1 Custom resistor type curve
2 Custom current/voltage curve
3 VDO 10Bar
4 CURTIS
5 VDO 5Bar
6 DATCON 10Bar
7 SGX
8 SGD
9 SGH
10 VOLVO-EC
11 SUZUKI
12 4-20mA 10Bar
13 0-5V 10Bar
14-15 Reserved
Factory default is resistor
type pressure sensor and
defined resistance’s
range is 0~6KΩ, default
is SGX sensor.
3
Liquid (Fuel) Level
Sensor
0 Not used
1 Custom resistor type curve
2 Custom current/voltage curve
3 SGD
4 SGH
5 SUZUKI
6-15 Reserved
Defined resistance’s
range is 0~6KΩ, default
is SGH sensor.
NOTE: pressure sensor and flexible sensor 1 connected input signals are resistor, current and voltage signals.
When configuring “custom current/voltage curve” via controller penal, X coordinate data need to be expanded tenfold,
for example, for 4mA, input data is “40”.
