HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 40 of 60
No
Items
Description
is inactive, gen-set will be stopped automatically.
30
Aux Manual Start
When input is active in manual mode, gen-set will be started
automatically. When input is inactive, gen-set will be stopped
automatically.
31
Simulate Up Key
Externally connecting a button to simulate key function on the panel.
32
Simulate Down Key
33
Simulate Stop Key
34
Simulate Manual Key
35
Reserved
36
Simulate Auto Key
Externally connecting a button to simulate key function on the panel.
37
Simulate Start Key
38
Simulate Gen C/O Key
39
Simulate Mains C/O Key
40
Rise Speed Pulse In
When engine type is 35 MTSC1 and is active, the pointed engine
speed increases 50RPM.
41
Drop Speed Pulse In
When engine type is 35 MTSC1 and is active, the pointed engine
speed decreases 50RPM.
42
Idle Pulse Input
When engine type is 35 MTSC1 and is active, the pointed engine
speed goes to 800RPM.
43
Simulate Set Key
Externally connecting a button to simulate key function on the panel.
44
Simulate Return Key
45
Simulate Mains OK
In auto mode if input is active, then mains is OK.
46
Simulate Mains Fail
In auto mode if input is active, then mains is abnormal.
47
Alternative Config 1 Active
When input port is active, alternative configuration is available.
Alternative configuration can be set as different parameters, which
is convenient to select current configuration via input ports.
48
Alternative Config 2 Active
49
Alternative Config 3 Active
50
Reserved
