HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 51 of 60
NOTE: Detailed contents for SMS DETAIL return include: operating mode, mains voltage, gens voltage, load current,
mains frequency, gens frequency, active power, apparent power, power factor, battery voltage, D+ voltage, water
temperature, oil pressure, fuel level, speed, accumulated running time, genset status, alarm status.
16 CONNECTIONS OF CONTROLLER AND J1939 ENGINE
16.1 CUMMINS ISB/ISBE
Table 17 Connector B
Terminals of controller
Connector B
Remark
Aux. output port 1
39
Set it as “fuel output”;
Start relay output
-
Connected with starter coil directly;
Auxiliary output port 2
Expansion 30A relay;
providing battery voltage for
terminal 01,07,12,13;
Set it as “ECU power”;
Table 18 9-Pin Connector
Terminals of controller
9 pins connector
Remark
CAN_SCR
SAE J1939 shield
CAN communication shielding
line(connected with ECU terminal only);
CAN(H)
SAE J1939 signal
Impedance 120Ω connecting line is
recommended.
CAN(L)
SAE J1939 return
Impedance 120Ω connecting line is
recommended.
Engine type: Cummins ISB.
16.2 CUMMINS QSL9
Suitable for CM850 engine control module.
Table 19 50-Pin Connector
Terminals of controller
50 pins connector
Remark
Aux. output port 1
39
Set it as “fuel output”;
Start relay output
-
Connected to starter coil directly;
Table 20 9-Pin Connector
Terminals of controller
9 pins connector
Remark
CAN_SCR
SAE J1939 shield-E
CAN communication shielding
line(connected with ECU terminal only);
CAN(H)
SAE J1939 signal-C
Using impedance 120Ω connecting line;
CAN(L)
SAE J1939 return-D
Using impedance 120Ω connecting line;
Engine type: Cummins-CM850.
16.3 CUMMINS QSM11 (IMPORT)
It is suitable for CM570 engine control module. Engine type is QSM11 G1, QSM11 G2.
