HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 56 of 60
16.14 PERKINS
It is suitable for ADEM3/ ADEM4 engine control module. Engine type is 2306, 2506, 1106, and 2806.
Table 37 Connector
Terminals of controller
Connector
Remark
Aux. output port 1
1,10,15,33,34
Set it as “fuel output”;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
31
Using impedance 120Ω connecting line;
CAN(L)
32
Using impedance 120Ω connecting line;
Engine type: Perkins.
16.15 SCANIA
It is suitable for S6 engine control module. Engine type is DC9, DC12, and DC16.
Table 38 B1 Connector
Terminals of controller
B1 connector
Remark
Aux. output port 1
3
Set it as “fuel output”;
Start relay output
-
Connected to starter coil directly;
CAN_SCR
-
CAN communication shielding line;
CAN(H)
9
Using impedance 120Ω connecting line;
CAN(L)
10
Using impedance 120Ω connecting line;
Engine type: Scania.
16.16 VOLVO EDC3
Suitable engine control mode is TAD1240, TAD1241, and TAD1242.
Table 39 ―Stand Alone‖ Connector
Terminals of controller
“Stand alone” connector
Remark
Aux. output port 1
H
Set it as “fuel output”;
Start relay output
E
Aux. output 2
P
Set output 2 as "ECU power";
Table 40 ―Data Bus‖ Connector
Terminals of controller
“Data bus” connector
Remark
CAN_SCR
-
CAN communication shielding line;
CAN(H)
1
Using impedance 120Ω connecting line;
CAN(L)
2
Using impedance 120Ω connecting line;
Engine type: Volvo.
NOTE: When this engine type is selected, preheating time should be set to at least 3 seconds.
16.17 VOLVO EDC4
Suitable engine types are TD520, TAD520 (optional), TD720, TAD720 (optional), TAD721, TAD722,
and TAD732.
