16.11 MTU MDEC
Suitable for 2000 series and 4000 series with MTU engine type.
Table 32 X1 Connector
Terminals of controller
X1 Connector
Remark
Aux. output port 1
BE1
Set it as “fuel output”;
Start relay output
BE9
CAN_SCR
E
CAN communication shielding line(connected
with one terminal only);
CAN(H)
G
Using impedance 120Ω connecting line;
CAN(L)
F
Using impedance 120Ω connecting line;
Engine type: MTU-MDEC-303.
16.12 MTU ADEC(MODULE MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 33 ADEC (X1 Port)
Terminals of controller
ADEC (X1port)
Remark
Aux. output port 1
X1 10
Set it as “fuel output”;
X1 9 shall connect negative of battery.
Start relay output
X1 34
X1 33 shall connect negative of battery.
Table 34 SMART (X4 Port)
Terminals of controller
SMART (X4 port)
Remark
CAN_SCR
X4 3
CAN communication shielding line;
CAN(H)
X4 1
Using impedance 120Ω connecting line;
CAN(L)
X4 2
Using impedance 120Ω connecting line;
Engine type: MTU-ADEC.
16.13 MTU ADEC (SAM MODULE)
It is suitable for MTU engine with ADEC (ECU8) and SMART module.
Table 35 ADEC (X1 Port)
Terminals of controller
ADEC (X1port)
Remark
Aux. output port 1
X1 43
Set it as “fuel output”;
X1 28 shall connect negative of battery.
Start relay output
X1 37
X1 22 shall connect negative of battery.
Table 36 SAM (X23 Port)
Terminals of controller
SAM (X4 port)
Remark
CAN_SCR
X23 3
CAN communication shielding line;
CAN(H)
X23 2
Using impedance 120Ω connecting line;
CAN(L)
X23 1
Using impedance 120Ω connecting line;
Engine type: Common J1939.
