HGM7220N/HGM7220S GENSET CONTROLLER USER MANUAL
HGM7220N/HGM7220S Genset Controller 2019-02-28 Version 1.0 Page 32 of 60
No.
Items
Range
Default
Description
6
Description
LCD displays corresponding content when
input port is active.
Digital Input 7
1
Content Setting
(0-50)
0
User defined. For details please see table
12.
2
Active Type
(0-1)
0
0: Close; 1: Open
3
Active Range
(0-3)
2
0: From safety on delay; 1: From crank; 2:
Always; 3:Never
4
Active Action
(0-4)
3
0: Warning; 1: Shutdown; 2: Trip and Stop;
3: Trip; 4: Indication.
5
Active Delay
(0-20.0)s
2.0
Time from detecting input port is active to
confirmation.
6
Description
LCD displays corresponding content when
input port is active.
Relay Output Setting
Relay Output 1
1
Content Setting
(0-239)
1
User defined time period output 1(default:
output in preheat period). For details please
see table 11.
2
Output Type
(0-1)
0
0: Normally open; 1: Normally close.
Relay Output 2
1
Content Setting
(0-239)
35
Idle speed control.
For details please see table 11.
2
Output Type
(0-1)
0
0: Normally open; 1: Normally close.
Relay Output 3
1
Content Setting
(0-239)
29
Close generator output.
For details please see table 11.
2
Output Type
(0-1)
0
0: Normally open; 1: Normally close.
Relay Output 4
1
Content Setting
(0-239)
31
Close mains output.
For details please see table 11.
2
Output Type
(0-1)
0
0: Normally open; 1: Normally close.
Relay Output 5
1
Content Setting
(0-239)
38
ETS control.
For details please see table 11.
2
Output Type
(0-1)
0
0: Normally open; 1: Normally close.
Relay Output 6
1
Content Setting
(0-239)
48
Common alarm.
For details please see table 11.
2
Output Type
(0-1)
0
0: Normally open; 1: Normally close.
Cycle Start Setting
1
Cycle Start Enable
(0-1)
0
0: Disabled; 1: Enabled
2
Priority Selection
(0-1)
0
0: standby unit (slave unit); 1: Main unit
3
Master Running
(min)
(0-1440)
720
4
Obey Running
(min)
(0-1440)
720
