SmartLine SL1620 - Smartline Accessories

1
http://support.weathermatic.com
1.0 SmartLine Accessories
SLM4
4-Zone Module for
SL1600 only
420GLS
Rain Sensor for All
SmartLine® Models
SLM2
2-Zone Module for
SL800 only
SLM12
12-Zone Module
for SL4800 only
SmartLine® accessories available through your professional Weathermatic installer. For the Weathermatic distributor directory, go to
www.weathermatic.com.
STATUS
ZONE
PGM
SELECT
MODE
RUN
PROGRAM
ZONE
MASTER VALVE
POWER
1
R B
2
R B
3
R B
SLM48DM 2-Wire Module
PROGRAM
PORT
R B
SLM16DM, SLM24DM,
SLM48DM
SmartWire Decoder
Modules for SL1600 only
SL-AIRCARD,
SL-AIRCARDFLOW
Web-based control from
PC, tablet, smartphone.
Flow management option
SLW Series On-Site
Weather Sensors
SmartLine® Weather Sensors with rain
and freeze sensing
SLW1
Wired
3/4
1/4
inch
1/2
3/4
1/4
1/8
SLW5
Wireless
RFS5
Wireless rain/
freeze sensor
inch
1/2
3/4
1/4
1/8
