Parameter Description Default Units Suggested Adjustments
sensitivity of the
speed regulator
Normally, the default of 10 is used. An
increase to 20 will make the drive more
responsive. Too low of a value causes the
drive to have sluggish responsiveness.
Normally, the default of 2 is used.
Pulses
per revolution
Set this to match the encoder nameplate
PPR.
Torque
Limit
maximum
motoring torque
the drive can
It is recommended to set this to 250%.
Torq Limit
maximum
regenerative
torque the drive
can produce
It is recommended to set this to 250%.
The table below lists the Parameters for A4 Power Convert.
Table 3: Parameters for A4 Power Convert
Parameter Description Default Units Suggested Adjustments
Input
Voltage
Nominal line-to-
line AC input
voltage in RMS
Per
drive
model
VAC
Set the input voltage to match the
measured voltage across R, S, and T.
The table below lists the Parameters for A5 Motor.
Table 4: Parameters for A5 Motor
Parameter Description Default Units Suggested Adjustments
Power
output power on
the nameplate
drive
model
This parameter should be set to match the
motor nameplate power. This parameter is
automatically populated after a successful
U9 AUTOTUNE.
Mtr Rated
Voltage
Motor rated
voltage on the
nameplate
Per
drive
model
VAC
This parameter should be set to match the
motor nameplate voltage. This parameter
is automatically populated after a
Frequency
frequency on the
nameplate
This parameter should be set to match the
motor nameplate frequency.
This parameter is automatically populated
after a successful U9 AUTOTUNE.
Rated FLA
current on the
drive
This parameter should be set to match the
motor nameplate current. This parameter
