Smartrise C4 Startup Manual

Drive Startup Manual M1000
Page 14 © 2020 Smartrise Engineering, Inc. All Rights Reserved March 5, 2020
Parameter Description Default Units Suggested Adjustments
Ser Enc
Comm
Spd
Communication
speed between
the drive and
absolute encoder
1M/9600bps
1M/9600bps
500k/19200bps
1M/38400bps
1M/38400bps
This parameter should be
left at default.
Encoder
Connect
Rotation of the
encoder that the
drive interprets
as forward or
reverse
Forward
Forward
Reverse
This should be set to a phase
orientation that will let the
motor run without excessive
motor current.
The table below lists the Parameters for U8 Basic.
Table 12: Parameters for U8 Basic
Parameter Description Default Units Suggested Adjustments
Control
Method
Sets the type of
motor control
technique
Closed
Loop Vect
Closed Loop
Open Loop Vector
PM ClosedLoopVct
V/f Control
Set this parameter to PM
Closed Loop Vect.
The table below lists the Parameters for U9 Autotune.
Table 13: Parameters for U9 Autotune
Parameter Description Default Units Suggested Adjustments
PM
Tuning
Mode
Sets the type of
autotuning the
drive performs
TuneNo
Rotate
Standard Tuning
Tune-No Rotate
Term Resistance
InitPoleEstPrms
PolePos-norotate
PolePos - rotate
Ind VoltageConst
Perform the Tune-No
Rotate, InitPoleEstPrms, and
PolePos-norotate in that
order.
Operation
Run the car and complete the checklist during the verification process.
No Faults
Make sure the car is moving without triggering a fault either on the Smartrise MR board or the
drive. If the MR board is faulted, see the C4 User Manual. If the drive is faulted, see the
Magnetek M1000 Manual.
