Smartrise C4 Startup Manual

Drive Startup Manual M1000
March 5, 2020 ©2020 Smartrise Engineering, Inc. All Rights Reserved Page 9
Parameter Description Default Units Suggested Adjustments
is automatically populated after a
successful U9 AUTOTUNE.
Number of
Poles
Number of poles
the motor has
4
--
This parameter should be set to match the
number of poles inside the motor. This
parameter is automatically populated
after a successful U9 AUTOTUNE.
Motor
Rated Slip
Slip frequency of
the motor
Per
drive
model
Hz
It is recommended that this setting be
determined by a U9 AUTOTUNE.
No-Load
Current
Magnetizing
current of the
motor
Per
drive
model
A
It is recommended that this setting be
determined by a U9 AUTOTUNE.
Leak
Inductance
Inductance of the
motor
Per
drive
model
%
It is recommended that this setting be
determined by a U9 AUTOTUNE.
Term
Resistance
Resistance of the
motor
Per
drive
model
∧
It is recommended that this setting be
determined by a U9 AUTOTUNE.
The table below lists the Parameters for C1 User Switches.
Table 5: Parameters for C1 User Switches
Parameter Description Default Units Suggested Adjustments
Motor
Rotation
Rotation of the
motor that the
drive interprets
as up or down
Forward Forward
Reverse
If the elevator is running controlled
but in the wrong direction, swap BOTH
this parameter and Encoder Connect.
The table below lists the Parameters for U8 Basic.
Table 6: Parameters for U8 Basic
Parameter Description Default Units Suggested Adjustments
Control
Method
Sets the type of
motor control
technique
Closed
Loop Vect
Closed Loop
Open Loop Vector
PM ClosedLoopVct
V/f Control
Set this parameter to
Closed Loop Vect.
