13
Setting up your monitor
1.Insert the memory card and/or connect HDD device to USB port. It supports up to 128GB
memory card to store security video clip or copy/backup a video clip from HDD. For long term
recording video, we suggested that you connect an external HDD which supperts up to 2TB.
Suggested memory card:
a. Sandisk 128GB/class-10
b. kingston 128GB/class-10
c. Sony 128GB/class-10
d. Samsung 128GB/class-10
Note:
‧
Make sure the monitor is power off before connecting your HDD/flash disk.
‧Max USB power supported to HDD/flash disk is 5V/1000mA. Please use the external
power
supply for the HDD/flash disk, if the HDD/flash disk require power supply higher than
1000mA.
‧Format your HDD/flash disk and/or SD card on CS97DVR first before using, following steps
as shown in "storage setup" section.
Memory Card Slot
USB Port connect to
HDD/Flash Disk
